RTS390 Total Station
description1
Zipper closure
1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in
place during workout
Features
Large color screen with touch interaction
28 keys with backlight function
Automatic correction for temperature and air pressure
Integrated compensation, fast and accurate
USB flash drive, Type-C, Bluetooth
Technical Data
| Telescone | |
|---|---|
| Imaging | Erect |
| Magnification | 30x |
| Field of view | 1°30' |
| Shortest focusing distance | 1.0m |
| Effective aperture | 45mm |
| Resolution | 4" |
| Compensator | |
|---|---|
| Type | integrated dual-axis compensator |
| Compensation range | ±6' |
| Data storage | |
|---|---|
| Memory | 30000 points(Onboard flash) |
| Extensibility | USB - HOST(TYPE - A HOST) |
| Data transfer | RS232/USB - OTG (TYPE - C SLAVE) |
| Laser plummet | |
|---|---|
| Type | laser plummet |
| Accuracy | ±1.0mm/1.5m |
| Spot diameter | 2.5mm/1.5m |
| Brightness | adjustable |
| Angle Measure | |
|---|---|
| Accuracy | 1/2" |
| Method | Absolute encoder |
| Detection mode | diametral 2/4 channel linear array CMOS |
| Distance Measure | |
|---|---|
| Range | prism 5000m reflectorless 1000m reflective sheet 1000m |
| Accuracy | 2mm + 2×10⁻⁶D(Prism) |
| Time | Fine mode: 0.5s Fast mode: 0.3s Track mode: 0.25s |
| Min. reading | 1mm/0.1mm optional 1"/0.1" optional |
| Power | |
|---|---|
| Battery | lithium - ion battery, 7.4V/2500mAh |
| Working time | 8 hours |
| Other | |
|---|---|
| Keyboard display | double - faced |
| Display screen | 6-line character,3.5-inch colour screen with resistive touch support |
| Keys | switchable input of numbers/letters/symbols, button backlight |
| Temperature and air pressure | Automatic temperature and pressure correction |
| External power supply | DC7.5V - DC12V |
| Weight | 6.0kg (battery included) |
| Working temperature | -20°C - +50°C |
| Waterproof and dustproof grade | IP55 |
