Far measuring range:≤110m
Accuracy:EL03≤±0.3mm, EL302A≤±0.7mm
Reliable reading, even in dim light conditions
Onboard programs, such as BF, BFFB, BFBF, BBFF, FBBF, stake out, intermediate
LCD display presents all important measured data at a glance and shows the next step to take
Quicker and easier than an optical level; Easy one-touch operation, simply push the MEAS button
Quick height and distance result - the reading is displayed almost instantly with measurement
|
EL03 |
EL302A |
|
|
Accuracy |
||
|
Standard deviation of 1km double run(ISO 17123 - 2) |
||
|
Electronic measurement |
±0.3mm* |
±0.7mm* |
|
Optical measurement |
±1.5mm* |
±1.5mm* |
|
Electronic measurement |
||
|
Time for single measurement |
≤2s |
≤2s |
|
Time for single measurement |
2 - 110m |
2 - 105m |
|
Measurement modes |
Single, average, tracking |
|
|
Display resolution(m/inch selectable for EL03/EL302A ) |
||
|
Height |
0.01mm/0.00001ft |
0.01mm/0.00001ft |
|
Distance |
1mm/0.001ft |
1mm/0.001ft |
|
Telescope |
||
|
Clear objective aperture |
45mm |
45mm |
|
Magnification |
30× |
30× |
|
Field of view at 100m |
2.6m |
2.6m |
|
Shortest focus distance |
1.0m |
1.0m |
|
Automatic compensator |
||
|
Working range |
14′ |
14′ |
|
Setting accuracy |
±0.3″ |
±0.5″ |
|
Power |
||
|
Battery |
2000mAh Ni - MH rechargeable |
2000mAh Ni - MH rechargeable |
|
Continuous operation time |
12 hours(At + 12℃) |
12 hours(At + 12℃) |
|
Measurement programs |
||
|
On - board programs |
BF, BFFB, BFBF, BBFF, FBBF, Stake out, intermediate |
|
|
Onboard adjustment |
YES |
|
|
Others |
||
|
Memory |
3000 points, support SD card |
|
|
Display |
LCD, 7linesX32characters |
|
|
Keyboard |
Alphanumerical keyboard |
|
|
Interface |
RS - 232C |
|
|
Sensitivity of circular level |
8′/2mm |
|
|
Water and dust protection |
IP54 |
|
|
Operating Temp |
- 20℃~ + 50℃ |
|
|
Net Weight |
3kg |
|
